Description
The POLYFORM® CCE-3 is a heavy duty mooring buoy, ready assembled with an iron rod and swivel. The rod and the swivel at the lower end are hot dipped galvanized. Upper part and the grip ring on top of the iron are coated with a dark blue plastic material. Mooring should only be attached to the bottom swivel end and not using the upper grip ring.
Specifications
- Diameter (max recommended): 450 mm
- Total length of steel rod: 765 mm
- Rod diameter: 19 mm
- Weight (nominal): 7,0 Kg
- Valve type: V10
- Gross volume: 55 L
- Recommended mooring weight: 31,5 Kg
Mooring Usage
Only the lower swivel shall be used for mooring. Do not expose the buoy to a load of more than 60% of its total buoyancy. All mooring shall be checked for wear and tear once a year.
Technical Files
